1.Upper and lower valve linkage of feeding device, ensure material in free fall which improves the penetration of the air stream to create better cooling effect.
2.The strong air jet and the double pressure door wind lock technology ensures the air volume is more than 2.5 times of that of the conventional rice whitener which can effectively restrain the temperature rise.
3.New type of feed hopper altered the direction of the original suction, realize cold rice into the machine.
4.Newly designed rice cooling tank adopts the principle of vertical aspiration duct, increases the cool air volume. Dynamic cooling of rice can be realized. The temperature of rice discharged is 1°C lower than the original design.
| Model | Capacity (t/h) | Power (kw) | Air volume (m3/h) | Wind resistance (pa) | Dimension (mm) |
| MNMF 18x2A | 5-6 | 37/45/55+3 | 2800-3500 | 1500-2000 | 1972x1000x2066 |
| MNMF 25x2A | 7-8 | 55/75+3 | 1500-2000 | 3600-4200 | 2080x1000x2108 |
| MNMF 18x2A ( Double motor ) | 5-6 | (18.5/22/30)x2+3 | 2800-3500 | 1500-2000 | 2000x1140x2055 |
| MNMF 25x2A ( Double motor) | 7-8 | (30/37)x2+3 | 3600-4200 | 1500-2000 | 2010x1140x2097 |
1.Upper and lower valve linkage of feeding device, ensure material in free fall which improves the penetration of the air stream to create better cooling effect.
2.The strong air jet and the double pressure door wind lock technology ensures the air volume is more than 2.5 times of that of the conventional rice whitener which can effectively restrain the temperature rise.
3.New type of feed hopper altered the direction of the original suction, realize cold rice into the machine.
4.Newly designed rice cooling tank adopts the principle of vertical aspiration duct, increases the cool air volume. Dynamic cooling of rice can be realized. The temperature of rice discharged is 1°C lower than the original design.
| Model | Capacity (t/h) | Power (kw) | Air volume (m3/h) | Wind resistance (pa) | Dimension (mm) |
| MNMF 18x2A | 5-6 | 37/45/55+3 | 2800-3500 | 1500-2000 | 1972x1000x2066 |
| MNMF 25x2A | 7-8 | 55/75+3 | 1500-2000 | 3600-4200 | 2080x1000x2108 |
| MNMF 18x2A ( Double motor ) | 5-6 | (18.5/22/30)x2+3 | 2800-3500 | 1500-2000 | 2000x1140x2055 |
| MNMF 25x2A ( Double motor) | 7-8 | (30/37)x2+3 | 3600-4200 | 1500-2000 | 2010x1140x2097 |
